22 - Kona - Libre CR/DL - 56cm - Purple - Ex Demo

$1,829.00

22 - Kona - Libre CR/DL - 56cm - Purple - Ex Demo—

$1,829.00

22 - Kona - Libre CR/DL - 56cm - Purple - Ex Demo—

$1,829.00

The Story

The cream of the crop, the Libre CR DL leaves no stone…er piece of gravel unturned. This gorgeous Race Light Carbon frame provides both performance and comfort across varying terrain. Powered by your legs and an 11-speed Shimano GRX 810 drivetrain, the Libre CR DL shifts with confidence in the mud, on pavement, over singletrack… With a +RAD adjustable dropper post, 700x45c WTB Riddler TCS tires, an Easton EA 70AX wheelset, and a Kona Verso Carbon fork that can carry a ton of gear, the Libre CR DL is the perfect weapon for any adventure, no matter how far away.

“With ample gear mounts…the Libre DL is a highly customizable and versatile bike.”

– Peloton Mag

Frame Material: Kona Race Light Carbon
Fork: Kona Verso Full Carbon Flat Mount Disc
Wheels: Easton EA 70AX 700c
Crankset: Shimano GRX 810
Drivetrain: Shimano GRX 810 11spd
Brakes: Shimano GRX 810 160mm front/160mm rear rotor
Seat Post: TranzX Dropper +RAD Internal 31.6mm
Cockpit: Easton EC70AX bar/Easton EA90 Stem with Velo Shock Proof Bar Tape
Front Tire: WTB Riddler TCS DUAL 700x45c
Rear tire: WTB Riddler TCS DUAL 700x45c
Saddle: WTB SL8

SPECS & GEOMETRY

SPECIFICATIONS

Frame Material	Kona Race Light Carbon
Sizes	50, 52, 54, 56, 58
Rear Shock	n/a
Fork	Kona Verso Full Carbon Flat Mount Disc
Crankarms	Shimano GRX 810
Chainrings	40t
B/B	Shimano PF86
Pedals	n/a
Chain	Shimano 105
Cassette	Shimano SLX 11-42t 11spd
Chainguide	n/a
F/D	n/a
R/D	Shimano GRX 810
Shifters	Shimano GRX 810 w/ Integrated Dropper Lever
Brake Calipers	Shimano GRX 810
Front Brake Rotor	Shimano RT54 160mm (centerlock)
Rear Brake Rotor	Shimano RT54 160mm (centerlock)
Brake Levers	Shimano GRX
Headset	FSA No.42ACB
Handlebar	Easton EC70AX
Stem	Easton EA90
Seatpost	TranzX Dropper +RAD Internal 31.6mm
Seat Clamp	Kona Clamp
Grips	Velo Shock-Proof Bar Tape
Saddle	WTB SL8
Front Hub	Easton EA 70AX 100x12mm
Rear Hub	Easton EA 70AX 142x12mm
Spokes	Easton EA 70AX Wheelset
Rims	Easton EA 70AX Wheelset
frontire	WTB Riddler TCS DUAL 700x45c
Rear Tire	WTB Riddler TCS DUAL 700x45c
Paint Color	Gloss Metallic Black w/ Magenta, Yellow & Supernova Fade Decals

All specifications are subject to change without notice

GEOMETRYmminches

	Size	50	52	54	56	58
1	ST Length	455	490	510	540	550
2	TT Length	543	558	572	588	608
3	Reach	378	383	386	389	394
4	Stack	575	590	610	630	660
5	Standover	758	782	803	830	850
6	HT Angle	70.5	70.5	71	71	71
7	HT Length	137.3	153.2	175.4	196.5	230.4
8	ST Angle	74	73.5	73	72.5	72
9	CS Length	440	440	440	440	440
10	BB Drop	75	75	72	72	70
11	BB Height	285	285	288	288	290
12	Wheelbase	1042	1052	1058	1068	1084
13	Front Center	613	623	628	638	654
14	Fork Length	410	410	410	410	410
15	Fork Offset	50	50	50	50	50
